CREO DLX Large Diameter Rod System

COMPANY: Globus Medical

SPECS

Product Category: Spinal Implants

By Product Type: Screws

Screw Type: Pedicle Screws (Thoraco-lumbar)

Features: Fenestrated , Polyaxial Head , Extended Reduction Head Tabs

Screw Materials: Titanium

By Location/Approach: Posterior Thoracic , Posterior Lumbar

By Procedure Type: TLIF , PLIF

By System Type: Degenerative , Deformity

By Material: Titanium (Solid)

DESCRIPTION

CREO DLX: 6.0 and 6.35mm Large diameter rod system

The CREO DLX by Globus Medical is a large diameter rod system utilizing the 6.0 and 6.35mm diameter rods. This system is primarily intended for thoracolumbar fixations where complex spinal pathologies require increased strength of the construct such as complex deformity, tumor, and trauma. The CREO DLX system also has a fenestrated screw which comes preloaded with polyaxial head.

Screw Options

DLX polyaxial screw:


  •  25° angulation (50° total cone of angulation)
  •  Accepts 6.0 or 6.35mm diameter rod
  •  Screw diameters: 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.5, 8.5, 9.5, 10.5, 11.5mm
  •  Screw lengths: 20-140mm
  DLX Dual Outer Diameter (DOD) Screws
  • Increased purchase in sacrum and ilium
  •  ±25° angulation (50° total cone of angulation)
  •  Available in proximal/distal outer diameters: 5.5/4.5mm, 6.5/5.0mm, 7.5/6.0mm, 8.0/6.5mm, 8.5/7.0mm, 9.5/8.0mm, 10.5/9.0mm
  •  Screw lengths: 30-120mm
  DLX Uniplanar Screw
  •  Deformity correction screw
  •  ±20° angulation in the cranial-caudal direction
  •  Screw diameters: 4.0, 4.5, 5.0, 5.5, 6.5, 7.5mm
  •  Screw lengths: 25-55mm
 DLX Fenestrated Screws
  • 25° angulation (50° total cone of angulation)
  •  Screw diameters: 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.5, 8.5, 9.5, 10.5, 11.5mm
  •  Screw lengths: 20-140mm

Product Brochures and Guides
