ELLIPSE Occipital-Cervical-Thoracic (OCT) posterior fusion

COMPANY: Globus Medical

SPECS

Product Category: Spinal Implants

By Product Type: Screws

Plate Location: Occipital

Screw Type: Posterior Cervical (Lateral Mass) , Pedicle Screws (Cervico-Thoracic)

Features: Polyaxial Head , Self Tapping

Screw Materials: Titanium

By Location/Approach: Posterior Cervical , Posterior Thoracic

By Procedure Type: PCF

By System Type: Degenerative

By Material: Titanium (Solid)

DESCRIPTION

The ELLIPSE OCT Occipital-Cervical-Thoracic Posterior fusion system which is designed for simplifying the process of posterior fusions. Distinguishing features of this system include the non-threaded locking cap which eliminates the risk of cross-threading. In addition, the screw heads feature ElliptiClick technology which allows the rod to click into and be held in place during construct placement.

Features:

  • ElliptiClick: rod retention system which clicks and hold rod during assembly
  • Cap Locking mechanism eliminates cross threading
  • 80 degrees of screw angulation (+40 degree)
  • Screw diameter: 3.5, 4.0, and 4.5mm
  • Screw lengths: 8-50mm
  • Smooth shoulder screws available (C1 non threaded shoulder)
  • Rods include tapered transition rods:
    • 3.5 to 4.0mm, 4.5mm, 5.0mm, 5.5mm, 6.0mm, 6.35mm, 6.5mm
    • Pre-bent rods in 3.5mm
    • 3.5mm occipital hinged rods

Product Brochures and Guides
