Omni VBR Expandable Thoracolumbar Vertebral Body Replacement

SPECS

Product Category: Spinal Implants

By Product Type: Interbody Device

Cage Type: Corpectomy Cage/Thoracic,Lumbar

Expansion: Expandable

Expansion Type/Lordosis: Parallel expansion (Fixed Lordosis)

Cage Approach: Anterior , Posterior

Configuration: Cage Alone

By Material: Titanium (Solid)

By Location/Approach: Anterior/Lateral Thoracic , Posterior Thoracic , Anterior Lumbar , Posterior Lumbar

By Procedure Type: Thoraco-lumbar Corpectomy

By System Type: Degenerative , Deformity , Trauma

DESCRIPTION

Omni VBR by Ulrich Medical USA is an expandable vertebral body replacement device made of titanium alloy and designed for surgical reconstruction of defects of the thoracic and lumbar spine (T1-L5), from anterior or posterior approach. Continuous expansion in situ is gear driven, and a locking screw is used for final fixation. Intended for use with supplemental fixation.

Features:

  • Continuous gear driven expansion in situ
  • Large center cavity for maximum autograft or allograft placement
  • 1.5 mm spikes for increased stability and to minimize migration
  • Height range options:
    • 19mm core
      • 15-22mm
      • 19-29mm
      • 24-38mm
      • 32-53mm
    • 22mm & 26mm core
      • 19-29mm
      • 24-38mm
      • 32-53mm
      • 46-80mm
    • 30mm core
      • 32-53mm
      • 46-80mm
  • Core Diameter options:
    • 19, 22, 26, and 30 mm
  • Lordosis options:
    • 0 and 8 degree
    • 16 degree (26mm diameter only)

Product Brochures and Guides
