CoRoent XLR PEEK ALIF Spacer

SPECS

Product Category: Spinal Implants

By Product Type: Interbody Device

Interbody Cage: Lumbar

Expansion: Static

Cage Approach: Anterior

Configuration: Cage Alone

By Material: PEEK Solid block

By Location/Approach: Anterior Lumbar

By Procedure Type: ALIF

By System Type: Degenerative , Deformity

DESCRIPTION

The CoRoent XLR PEEK ALIF spacer is designed for anterior lumbar approach with various footprints for variable patient anatomy, to be completed with a supplemental internal fixation system. The CoRoent XLR Line Extension includes a smaller footprint to address TLIF/PLIF revisions done anteriorly, small patient anatomy, and limited access provided by the access surgeon.

Features:

  • Radiolucent PEEK
  • Footprints (WxD):
    • 34 x 24 mm (8 degree only)
    • 38 x 28 mm
  • Heights:
    • 10 mm (8 degree only)
    • 12 - 20 mm (2mm increments)
  • Lordosis:
    • 8 degree
    • 15 degree (38x28 only)
  • XLR Line Extension:
    • WxD = 26 x 22 mm
    • H = 6, 8, 10 mm
    • L = 10 degree
