Rhausler Anterior Cervical Vertebrae Plate System

LEAVE A REVIEW

COMPANY: Rhausler, Inc.

MANUFACTURER INFO:Rhausler Anterior Cervical Vertebrae Plate System

SPECS

Product Category: Spinal Implants

By Product Type: Plates

Plate Location: Cervical

Plate Approach: Anterior Plate

Plate Configuration: Stand-Alone Plate

Plate Dynamics: Static Plate

By Location/Approach: Anterior Cervical

By Procedure Type: ACDF

By System Type: Degenerative , Deformity , Trauma

By Material: Titanium (Solid)

DESCRIPTION

The Rhausler Anterior Cervical Vertebrae Plate System offers multiple options for single and multi-level anterior cervical plates, intended for stablization of the anterior cervical spine. It offers three low-profile cervical plate options: Dynamic, Semiconstrained, and QuickPlate. The plates are made of titanium alloy, are available in 1-3 level designs in a range of sizes, and have an integrated self-locking CAM-lock mechanism for retention of the bone screws.

Three different plate designs:

Dynamic:
- 16 mm wide at the top and 19 mm wide at the bottom
- Fully dynamic, allowing up to 3mm of settling
- Additional bone graft screw holes
- Allows linear dynamic and axial rotational movement of the bone screw
Semiconstrained:
- 16 mm wide at the top and 19 mm wide at the bottom
- Semi-dynamic, allowing up to 1.5 mm of settling
- Additional bone graft screw holes
- Allows axial rotational movement of the bone screw
QuickPlate:
16 mm wide at the top and bottom
Large graft viewing windows
Stackable convex and concave ends for re-operations or multilevel plating
Allows axial rotational movement of the bone screw

Features:

Made of titanium alloy
Integrated self-locking CAM-lock mechanism
Plate length options:
- 1 level = 21-35 mm
- 2 level = 37-55 mm
- 3 level = 54-78 mm
- 4 level = 69-109 mm (dynamic and semiconstrained special order)
