WaveForm TA & TO 3D Printed TLIF & PLIF Spacer

SPECS

Product Category: Spinal Implants

By Product Type: Interbody Device

Cage Type: Interbody Cage/Lumbar

Expansion: Static

Cage Approach: Posterior/Straight (PLIF) Cage,Curved (TLIF) Banana Cage,Oblique Cages

Configuration: Cage Alone

By Material: 3D Printed Titanium

By Location/Approach: Posterior Lumbar

By Procedure Type: TLIF , PLIF

By System Type: Degenerative , MIS/Perc

DESCRIPTION

The WaveForm TO (TLIF Oblique) and WaveForm TA (TLIF Articulating) by Seaspine-Orthofix are a pair of 3D printed titanium TLIF and PLIF spacers that feature the waveform technology which is a repeating continuous wave-like internal structure that distributes the load evenly. Features large central graft window and multiple trabecular spaces to place graft.

Features:

  • 3D printed titanium
  • WaveForm technology with 65% endplate porosity and 75% body porosity to enhance bony ingrowth.
  • WaveForm TO (TLIF Oblique): Straight Spacer
    • Footprint options:
      • 9x24mm
      • 9x28mm
      • 11x28mm
      • 11x32mm
    • Height options:
      • 7-16mm
    • Lordosis options:
      • 5, 10, 15 degrees
  • WaveForm TA (TLIF Articulating): Curved TLIF Spacer
    • Footprint options:
      • 9x28mm
      • 9x32mm
      • 11x36mm
    • Height options:
      • 8-16mm
    • Lordosis options:
      • 8, 15 degrees
